UBP E-Cap Photo
  • Bi-polar capacitors for horizontal deflection circuits of TV sets
  • Low cost compared to film capacitors
  • Items with higher permissible ripple ratings are available upon request

CHARACTERISTICS

Part Number 25V ~ 22UBP 25V ~ 47UBP 25V ~ 68UBP 25V ~ 10UBP
Operating Temperature Range - 25 ~ +85°C
Rated Voltage Range 25V DC
Nominal Capacitance
at 120Hz, 20°C
2.2mF 4.7mF 6.8mF 10mF
Case Sizes ØD x L 16x25.5 mm 16x35.5 mm 16x35.5 mm 16x35.5 mm
Max. Ripple Current
at 15.75 kHz
6 Ap-p 7.5 Ap-p 8 Ap-p 10 Ap-p
Capacitance Tolerance
+ 20%(M) (at 20°C, 120 Hz)
Leakage Current
100mA (after 5 minutes) in both directions (at 20°C)
Dissipation Factor
0.05 max. (at 20°C, 120 Hz)
Temperature
Characteristics
Capacitance change shall be within ± 10% of the value at 20% over operating temperature range
Load Life The following specifications shall be satisfied when the capacitors are restored to 20°C after DC 12V and
specified ripple current are applied for 1000 hours at 85°C.
Capacitance Change £ ± 15% of the initial value
Dissipation Factor £ 200% of the initial specified value
Leakage Current £ The initial specified value


DIMENSIONS

Radial Lead Unit (mm)
ØD 16
F 7.5
Ød 0.8
L' L + 2.0 max.
ØD' ØD + 0.1
